Strandfloor installation quick reference and frequently asked questions
What sizes are Strandfloor Sheets?
All Strandfloor® types are available in the following sizes:
| 3600x1200x20mm | 20 sheets / pack | 60kg/sheet | 13.6kg/m2 |
| 2400x1200x20mm | 45 sheets / pack | 40kg/sheet | 13.6kg/m2 |
Strandfloor Square Edge is a made to order product. Please enquire with customer services for minimum order quantity and leadtime - csc@laminex.co.nz
What’s the Max Exposure Time for Strandfloor?
StrandfloorH3.1: 12 weeks
Strandfloor: 8 weeks
What Type of Nail or Screw Should I Use for solid and engineered timber joists?
| Type | Size |
|---|---|
| Annular Grooved Particleboard Flooring Nails (NZ Nails) | 60mm x 2.8-3.1 gauge |
| Galvanised Jolt Head Nails (NZ Nails) | Minimum 60mm |
| Self-Drilling Screws Corrosion Resistant (Bremick) | 45mm x 8 gauge |
| Self-Drilling Stainless Steel Screws (Bremick) | 50mm x 10 gauge |
| Simpson Strongtie SS Screw (SSWSC2BSA10) | 50mm x 10 gauge |
| Simpson Strongtie Zinc Screw (WSV50SA) | 50mm x 10 gauge |
| Beck Scrail SubLok Pro | 57mm x 2.8 gauge |
| Delfast Ring Shank Nail | 50mm x 2.8 gauge |
- Fixing Centres for all fastener types : 150mm (perimeter), 200mm (intermediates)
- All fasteners below are suitable for use in SED diaphragms.
- For full details please refer to the Strandfloor Technical Installation Manual
What Type Screw Should I Use for Steel joists?
Tek self-drilling corrosion resistant screw - 45mm x 10g
Fixing Quantities for Tongue & Groove Strandfloor
| Panel Size | 3600 x 1200 | 2400 x 1200 | ||
|---|---|---|---|---|
| Joist Centres | Nails/Screws | Adhesive | Nails/Screws | Adhesive |
| 600 mm | 53 | 0.6 | 39 | 0.4 |
| 450 mm | 67 | 0.7 | N/A | N/A |
| 400 mm | 74 | 0.8 | 53 | 0.5 |
Fixing Quantities for Square Edge Strandfloor Panels
| Panel Size | 3600 x 1200 | 2400 x 1200 | ||
|---|---|---|---|---|
| Joist Centres | Nails/Screws | Adhesive | Nails/Screws | Adhesive |
| 600 mm | 89 | 1 | 63 | 0.7 |
| 450 mm | 99 | 1.1 | N/A | N/A |
| 400 mm | 104 | 1.2 | 73 | 0.08 |
What Adhesive should I use for Strandfloor?
Timber joists: Sika Nailbond Premium | Bostik Alpha Grip | Gorilla Grip | HB Fuller Sturdi Bond
Steel joists: Sikaflex 123 MS Bond | Gorilla 940FC |Gorilla MS Sealant
Adhesive Application Instructions:
- Apply a 5mm continuous bead to the top of each joist.
- Apply adhesive between sheets at ends and edges.
- Apply a 2mm bead to the top of the tongue.
For full installation details please refer to the Strandfloor Installation Manual
